The brag page. Your chance to show off your rig...
Not listed or need to update your 'blueprint'? Please login to submit your specs.
Figures in brackets are [non-overclocked] and RAM timings are: T(RAS)-T(RCD)-T(RP)-CAS Latency
Unsure of program settings or versions? See the benchmark notes page for more info.
| Beorn2 | Enraged Stoat | FreddyK | Gandalf | Gandalf2 | HeMan | JRUDMAN | mauke_warrior | Narsil | Pommie Legend |
cpu:
Core 2 Quad Q9550@2.83GHz (333MHz x8.5) L2 Cache 12MB SLB8V
cool:
Stock HSF
m/b:
GIGABYTE EP45T-DS3R DDR3-1900(OC) FSB-1600MHz CrossfireX PCI-e 2.0 P45 + ICH10R Chipset LGA775
ram:
4GB X2 2GB DDR3 DUAL CHANNEL 1333MHz PC3-10600 CL9
grfx:
Force3D Radeon HD 4850 512MB GDDR3
hdd:
1.66TB Total. \\ 1TB WD green, 500GB WD AAKS SATAII, 160GB Maxtor SATA
cd/dvd:
HL-DT-SL DVDRAM GSA-4163B LG DVD/CD writer
psu:
OCZ 600W POWERSTREAM.
case:
iCute something or rather.
screen:
Chimei CMV 938D 19'' widesreen LCD 5ms response 1440x900 native rez
keybd:
Mini-keyboard.
mouse:
Logitech MX518.
o/s:
Windows 7 - 64 bit
Notes:
I am Yoda Dee.
Benchmarks:
Sisoft Sandra
CPU Arithmetic: Aggregate = 45 GOPS, Dhrystone = 52.17 GIPS, Whetstone = 37.69 GFLOPS
CPU Multimedia: Aggregate = 110.8 MPx/s, Integer = 131.59 MPx/s, Floating-Point = 90 MPx/s
CPU Crypto: Crypto B'width = 587 MB/s, AES256 Crypto = 478 MB/s, SHA256 Hash = 696 MB/s
Memory Bandwidth: Aggregate = 7 GB/s, Int Buff'd = 7 GB/s, Float Buff'd = 7 GB/s
Super PI mod v1.5 XS to one million places
16.843s
Windows 7 Experience Index
5.2 (based on hard drive transfer rate subscore)
Wishlist:
- 24'' LCD 1080p, response < 5ms
- CrossfireX with another HD4850 gfx card, 1GB version
- Core i7 System
cpu:
Core2Duo E8500 3.16Ghz
cool:
Standard
m/b:
Gigabyte EP45T-UD3P
ram:
4GB of OCZ Platinum DDR3 1333Mhz PC3-10666 dual channel @ 7-7-7-20
grfx:
BFG Tech GTX260 Maxcore + GeForce 9500GT
hdd:
178GB raid0 3x 64GB SSD (system). 10.5 TB raid5 8x 1.5TB Seagates (storage) on Highpoint RocketRAID 3520
cd/dvd:
Lite-On LH20A1L DVDRW
psu:
Ultra 650w modular
case:
Ultra m series
screen:
Dell 3007FPW 30'' TFT 2560x1600 (and a 2405FWP 24'' TFT 1900x1280 on the side)
keybd:
Das Keyboard Ultimate
mouse:
Razer Deathadder
o/s:
Vista 64
Notes:
It's quite heavy to cart around. Nothing is overclocked. Usually triple headed with a 30'' TFT and 2x 24''s.
Benchmarks:
Vista Experience Index
5.7
CrystalDiskMark 2.2 Sequential
C: 516MB/sec read, 45MB/sec write. D: 470MB/sec read, 1.1GB/sec write
CrystalDiskMark 2.2 Random 512k clusters
C: 1.3GB/sec read | 401MB/sec write. D: 1.3GB/sec read, 1GB/sec write
Super PI mod1.5 XS
1 million digits 14.972s
Counter Strike:Source Graphics Test
415 fps @ 2560x1600 max detail (noAA)
cpu:
Intel Core i7 950 Nehalem 3.06GHz 8MB 1333MHz LGA1366
cool:
Arctic Cooling Freezer 7 Pro Rev. 2
m/b:
ASUS Rampage III GENE Intel X58 i7 DDR3 PCI-E SLI & CrossFireX ATX
ram:
Corsair CMT6GX3M3A2000C8 6GB (3x2GB) DDR3-2000 CL8 Dominator GT Triple Channel
grfx:
PCI Express 1.0 x8: XFX GeForce 8800 GTS 320MB
hdd:
2x(320Gb Seagate Barracuda 7200.10) Raid0
cd/dvd:
GSA-4163B LG16x Super Multi DVD/CD ReWriter (Firmware A105)
psu:
Corsair HX650 650W Modular
case:
NZXT Vulcan Enthusiast M-ATX Gaming Case
screen:
ViewSonic VA912 19'' LCD, 8ms response, 1280x1024 native resolution
keybd:
Some old POS! Model number 104DAW15-319
mouse:
Logitech MX518
o/s:
Windows7x64
cpu:
Intel Core i5 2500K Sandy Bridge, 3.30GHz, 6MB Cache, 95W, Socket LGA1155
cool:
Stock retail fan
m/b:
ASUS P8Z68-M PRO, Intel Z68, LGA1155, 4xDDR3 up to 2200(OC), 2xUSB3, 2xSATA3 (6Gb/s), UEFI BIOS
ram:
Mushkin Ridgeback 8GB (2x4GB) DDR3 PC3-12800 CL8 (model 996998) Timings: 8-9-8-24 @1600MHz
grfx:
MSI nVidia GeForce GTX 560 Ti OC Edition (N560GTX-Ti Twin Frozr II/OC) 1024MB GDDR5 4200MHz Memory, 880MHz Core, DX11
hdd:
10TB total across 6 Western Digital SATA2 HDD's: 1x2TB Caviar Black, 3x2TB + 2x1TB Caviar Green
cd/dvd:
LG CH10LS20 10x Blu-ray Combo Lightscribe, SATA, Black
psu:
Corsair Professional HX650, 650W Modular Power Supply, 80 PLUS Bronze
case:
Thermaltake Armor A60 Mid Tower Case, Side Window, Black
screen:
Dual monitor setup:
ViewSonic VX2433WM 24'' LCD, 2ms response, Full HD 1080p, 1920x1080 native resolution, HDCP
ViewSonic VX922 19'' LCD, 2ms response, 1280x1024 native resolution
ViewSonic VX2433WM 24'' LCD, 2ms response, Full HD 1080p, 1920x1080 native resolution, HDCP
ViewSonic VX922 19'' LCD, 2ms response, 1280x1024 native resolution
keybd:
Microsoft Multimedia Keyboard 1.0A
mouse:
Microsoft Sidewinder X8 Wireless Gaming Mouse
o/s:
Windows 7 Home Premium SP1 (OEM) 64-bit
Notes:
Sounds via Altec Lansing VS2221 Speakers
cpu:
Intel Core 2 Duo E6750, 2.66GHz, 1333MHz FSB, Socket 775, 32/64-Bit
cool:
Stock retail fan (variable speed)
m/b:
ASUS P5Q SE2, Socket 775, Intel P45 chipset, up to 1600MHz FSB
ram:
4GB total: 2x Corsair XMS2 TWIN2X2048-6400 (ie 4x1GB sticks), DDR2-800, PC2-6400, CL5
grfx:
XFX Geforce 8800GT XXX Extreme Edition, 512MB GDDR3, GPU clock 670MHz, memory bus 256-bit. DX10
hdd:
1TB total: 2x500GB Seagate Barracuda, 7200rpm, 32MB Cache, SATA-2
cd/dvd:
ASUS DRW-24B3ST DVD writer (CD:48xR 48xW, DVD: 16xR 24xW)
psu:
Zalman ZM600-HP, Ultra-Quiet, 600W ATX PSU, Active PFC, Modular Cable System
case:
Thermaltake V4 Black Edition
screen:
Philips 19'' LCD, 1280x1024 native resolution
keybd:
Microsoft Multimedia Keyboard 1.0A
mouse:
Microsoft Wheel Mouse Optical
o/s:
Windows 7 Home Premium SP1 (OEM) 64-bit
Notes:
aka ''Alphadog''
cpu:
Intel Core i5 2500K Sandy Bridge 3.30GHz 6MB 95W LGA1155 @ 4.5Ghz
cool:
Prolimatech Megahalems Rev. B CPU Cooler LGA1366 LGA775 w/ Fan w/Bracket
m/b:
ASUS P8P67 Pro Rev 3.0 Intel P67 DDR3 USB3+SATA3 Raid SLI+ CrossFire LGA1155 PCI-E
ram:
Kingston HyperX 8GB (2x4GB) DDR3-1600 Kit CL9
grfx:
ASUS ENGTX580/2DI/1536MD5 Geforce GTX 580 OC 1536MB GDDR5 PCI-E
hdd:
Western Digital Caviar Blue 500GB WD5000AAKX 16MB Cache SATA3, Samsung Spinpoint F3 1TB 32MB 7200rpm SATAII
cd/dvd:
Lite-On Blue Ray Reader 8* DVD Writer
psu:
Seasonic X-Series 750W PSU 80PLUS Gold
case:
Lian-Li LanCool Dragonlord PC-K62B Black Interior w/Window
screen:
Samsung BX2300 23'' LED 2ms response, 1080p
keybd:
mouse:
o/s:
Microsoft Windows 7 OEM Home Premium 64Bit SP1
cpu:
Intel Core 2 Quad Q9300 2.50 GHz, 1333MHz FSB, Socket 775
cool:
default fan that came with cpu
m/b:
Gigabyte GA-EP35C-DS3R Motherboard, Socket 775, 1600MHz FSB, 4xDIMM DDR2, 2xDIMM DDR3, PCIe-16, 3xPCI, 3xPCIe-1, 12xUSB2, Audio, ATA, RAID, ATX
ram:
4GB 2x A-Data 800MHZ 2GB DESKTOP RAM, 1x2GB, DDR2-800, PC2-6400, CL5, DIMM
grfx:
Sapphire HD 4850 Video Card, Radeon HD 4850, 512MB, DDR3, PCIe-16, TV out, DVI, HDTV, CrossFire
hdd:
Total: 1.5 TB Seagate Barracuda : 500GB, Western Digital: 1TB Caviar Green
cd/dvd:
Asus DRW-2014L1T DVD Writer, DVD 16R/20W/8RW, CD 48R/48W/32RW, Internal, SATA, Black, LightScribe
psu:
EZCool Bluefire (140mm LED Fan), 600W ATX PSU, Titanium
case:
NZXT Lexa Blackline Blue LED Edition ATX Full Tower Case, Side Window, Black
screen:
keybd:
mouse:
o/s:
Windows XP Black 4.0 SP3
Notes:
External Harddrive
Western Digital 1TB
Benchmarks:
3DMark06
3DMark score = 12148, SM2 score = 4632, HDR/SM3 score = 5432, CPU score = 4068
Super PI mod v1.5 XS
1M dec.places = 20.250s
cpu:
Intel Core i5 2500K 3.3GHz Socket 1155 over clocked to 4.5GHZ with Intel Turbo Boost
cool:
Arctic Cooling Freezer 7 Pro Rev. 2
m/b:
Asus P8P67 PRO Intel P67 ATX 1155, CrossFireX SLI, USB3, Bluetooth (Revised B3 Chipset)
ram:
A-RAM DDR3 PC-12800 1600MHz, PRO series Memory 4x 2GB sticks (8GB total)
grfx:
Gigabyte GV-R685OC-1GD Overclocked HD 6850 1GB
hdd:
Kingston SSDNow V100 SV100S2 64GB (O/S), 1TB WD Green, 2TB, WD Green, 300GB,
cd/dvd:
Samsung 22X dvd dl rw
psu:
750W Aywun MEGA POWER ECO Series A1-750E
case:
Thermaltake Armor A60 VM20001W2Z
screen:
LG E2350V-PN LED HDMI Monitor - 23''
keybd:
LASER USB Multimedia VoIP keyboard (KB-USBBKVPU)
mouse:
Microsoft Sidewinder gaming mouse
o/s:
Windows 7 Black 64bit
Notes:
- Acer Aspire One 8.9'' Netbook with xp black 30
- Xbox 360 running custom modified firmware to play backup games
- Knife
- Flamethrower
- Xbox 360 running custom modified firmware to play backup games
- Knife
- Flamethrower
cpu:
Athlon 64 x2 4200+ (Manchester) 2.2Ghz
cool:
Stock AMD heat sink and fan
m/b:
GA-K8NF-9 939 Socket nForce4-4X Chipset
ram:
2048Mb DDR: 2x OCZ 512Mb PC3200 DDR400 @ CL 8-4-4-2.5 (Dual Channel), 2x Corsair 512MB PC3200 @ CL 8-3-3-2.5 (Dual Channel)
grfx:
Gigabyte 8800GT
hdd:
1.76 TB total: 120GB Seagate Barracuda ATA/100 + 640GB Western Digital Caviar Black SATA + 1TB Western Digital Caviar Green SATA
cd/dvd:
LG GSA-4163B 40x24x40x16x6x16
psu:
Enermax EG495P-SFMA24P, NoiseTaker, 485W
case:
Meridian Clio II ATX (beige finish)
screen:
keybd:
mouse:
o/s:
Windows XP Home SP3
Notes:
Still flying the AMD flag.
Member of the terabyte club
Member of the terabyte club
cpu:
Intel Core2Duo 6420
cool:
Stock
m/b:
Asus P5N-E SLI
ram:
2Gb DDR2-800
grfx:
Albatron 8600 GTS
hdd:
400Gb Seagate Barracuda hard drive
cd/dvd:
LG DVD writer
psu:
Enermax Liberty 500W
case:
Lian-Li PC7B plus II
screen:
keybd:
mouse:
o/s:
Windows XP Pro SP2 dual-booting with Xubuntu
